SPECIFICATIONS
| POWER TYPE | Diesel Electric |
| BUILDER | Brush Traction, Loughborough |
| WHEEL ARRANGEMENT | Co-Co |
| WHEELBASE | 56ft 3in |
| DIMENSIONS | H-12ft 10.75/ L-70ft / W-8ft 8in |
| WEIGHT | 129 ton |
| WHEEL DIAMETER | 43in |
| ENGINE | Mirlees 8MB275T |
| TRAIN BRAKES | Air |
| BRAKE FORCE | 74 tonnes |
| FUEL CAPACITY | 990 gals |
| POWER OUTPUT | 3100hp |
| TRACTIVE EFFORT | 106500lb |
| MAX SPEED | 60mph |
| BUILT / WITHDRAWN | 1989-93/ - | No. BUILT | 100 |
RETURN TO LIST OF CLASS TYPES
RETURN TO LIST OF LOCO NUMBERS
LOCOMOTIVES IN CLASS
| REGION OR CLASS |
REGION No. |
1948 No. | 1957 No. | TOPS No. | RENUMBER | STATUS | LOCO FACTS |
|---|---|---|---|---|---|---|---|
| 60 | 60001 | Commercial | 60001 | ||||
| 60 | 60002 | Commercial | 60002 | ||||
| 60 | 60003 | Commercial | 60003 | ||||
| 60 | 60004 | Commercial | 60004 | ||||
| 60 | 60005 | Commercial | 60005 | ||||
| 60 | 60006 | Scrapped | 60006 | ||||
| 60 | 60007 | Commercial | 60007 | ||||
| 60 | 60008 | Commercial | 60008 | ||||
| 60 | 60009 | Commercial | 60009 | ||||
| 60 | 60010 | Commercial | 60010 | ||||
| 60 | 60011 | Commercial | 60011 | ||||
| 60 | 60012 | Commercial | 60012 | ||||
| 60 | 60013 | Commercial | 60013 | ||||
| 60 | 60014 | Commercial | 60014 | ||||
| 60 | 60015 | Commercial | 60015 | ||||
| 60 | 60016 | 60500 | Commercial | 60016 - 60500 | |||
| 60 | 60017 | Commercial | 60017 | ||||
| 60 | 60018 | Commercial | 60018 | ||||
| 60 | 60019 | Commercial | 60019 | ||||
| 60 | 60020 | Commercial | 60020 | ||||
| 60 | 60021 | Commercial | 60021 | ||||
| 60 | 60022 | Commercial | 60022 | ||||
| 60 | 60023 | Commercial | 60023 | ||||
| 60 | 60024 | Commercial | 60024 | ||||
| 60 | 60025 | Commercial | 60025 | ||||
| 60 | 60026 | Commercial | 60026 | ||||
| 60 | 60027 | Commercial | 60027 | ||||
| 60 | 60028 | Commercial | 60028 | ||||
| 60 | 60029 | Commercial | 60029 | ||||
| 60 | 60030 | Commercial | 60030 | ||||
| 60 | 60031 | Commercial | 60031 | ||||
| 60 | 60032 | Commercial | 60032 | ||||
| 60 | 60033 | Commercial | 60033 | ||||
| 60 | 60034 | Commercial | 60034 | ||||
| 60 | 60035 | Commercial | 60035 | ||||
| 60 | 60036 | Commercial | 60036 | ||||
| 60 | 60037 | Commercial | 60037 | ||||
| 60 | 60038 | Commercial | 60038 | ||||
| 60 | 60039 | Commercial | 60039 | ||||
| 60 | 60040 | Commercial | 60040 | ||||
| 60 | 60041 | Commercial | 60041 | ||||
| 60 | 60042 | Commercial | 60042 | ||||
| 60 | 60043 | Commercial | 60043 | ||||
| 60 | 60044 | Commercial | 60044 | ||||
| 60 | 60045 | Commercial | 60045 | ||||
| 60 | 60046 | Commercial | 60046 | ||||
| 60 | 60047 | Commercial | 60047 | ||||
| 60 | 60048 | Commercial | 60048 | ||||
| 60 | 60049 | Commercial | 60049 | ||||
| 60 | 60050 | Preservation | 60050 | ||||
| 60 | 60051 | Commercial | 60051 | ||||
| 60 | 60052 | Commercial | 60052 | ||||
| 60 | 60053 | Commercial | 60053 | ||||
| 60 | 60054 | Commercial | 60054 | ||||
| 60 | 60055 | Commercial | 60055 | ||||
| 60 | 60056 | Commercial | 60056 | ||||
| 60 | 60057 | Commercial | 60057 | ||||
| 60 | 60058 | Commercial | 60058 | ||||
| 60 | 60059 | Commercial | 60059 | ||||
| 60 | 60060 | Commercial | 60060 | ||||
| 60 | 60061 | Commercial | 60061 | ||||
| 60 | 60062 | Commercial | 60062 | ||||
| 60 | 60063 | Commercial | 60063 | ||||
| 60 | 60064 | Commercial | 60064 | ||||
| 60 | 60065 | Commercial | 60065 | ||||
| 60 | 60066 | Commercial | 60066 | ||||
| 60 | 60067 | Commercial | 60067 | ||||
| 60 | 60068 | Commercial | 60068 | ||||
| 60 | 60069 | Commercial | 60069 | ||||
| 60 | 60070 | Commercial | 60070 | ||||
| 60 | 60071 | Commercial | 60071 | ||||
| 60 | 60072 | Commercial | 60072 | ||||
| 60 | 60073 | Commercial | 60073 | ||||
| 60 | 60074 | Commercial | 60074 | ||||
| 60 | 60075 | Commercial | 60075 | ||||
| 60 | 60076 | Commercial | 60076 | ||||
| 60 | 60077 | Commercial | 60077 | ||||
| 60 | 60078 | Commercial | 60078 | ||||
| 60 | 60079 | Commercial | 60079 | ||||
| 60 | 60080 | Commercial | 60080 | ||||
| 60 | 60081 | Commercial | 60081 | ||||
| 60 | 60082 | Commercial | 60082 | ||||
| 60 | 60083 | Commercial | 60083 | ||||
| 60 | 60084 | Commercial | 60084 | ||||
| 60 | 60085 | Commercial | 60085 | ||||
| 60 | 60086 | Preservation | 60086 | ||||
| 60 | 60087 | Commercial | 60087 | ||||
| 60 | 60088 | Commercial | 60088 | ||||
| 60 | 60089 | Commercial | 60089 | ||||
| 60 | 60090 | Commercial | 60090 | ||||
| 60 | 60091 | Commercial | 60091 | ||||
| 60 | 60092 | Commercial | 60092 | ||||
| 60 | 60093 | Commercial | 60093 | ||||
| 60 | 60094 | Commercial | 60094 | ||||
| 60 | 60095 | Commercial | 60095 | ||||
| 60 | 60096 | Commercial | 60096 | ||||
| 60 | 60097 | Commercial | 60097 | ||||
| 60 | 60098 | Commercial | 60098 | ||||
| 60 | 60099 | Commercial | 60099 | ||||
| 60 | 60100 | Commercial | 60100 |
